Nominal Frequency Range: 0.7 – 9 GHz
Useable Frequency Range: 0.6 – 10.5 GHz
Impedance: 50 Ω
Connector: N-type female
Mounting Tube: ⌀22 mm, Length = 215 mm
Isotropic Gain: typ. 10.3 dBi ±1.5 dB
Antenna Factor: 18…41 dB/m
SWR (typical): < 1.5 (for f < 7 GHz)
Max. Input Power: 300 W (f=1 GHz)/ 150 W (f=6 GHz)
Half-Power Beamwidth (E-plane): 46° ±10°
Half-Power Beamwidth (H-plane): 48° ±10°
Front-to-Back Ratio: 25 dB (typical)
Cross-Polarisation Rejection: 30 dB (typical)
Dimensions (W x H x D): 460 (+215) × 270 × 270 mm
Weight: 3.7 kg
