Nominal Insertion Loss in 50 Ω System: 16 dB
Transfer Impedance: 8 Ω
Nominal Frequency Range: 900 kHz – 200 MHz
Usable Frequency Range: 9 kHz – 200 MHz
Conversion (Voltage → Current): 8 µV = 1 µA (Equivalent: 18 dBµV = 1 dBµA)
Usable Frequency Range with AC 5 A (50 Hz, –1 dB): 50 kHz – 200 MHz
Usable Frequency Range with AC 10 A (50 Hz, –1 dB): 80 kHz – 200 MHz
Usable Frequency Range with AC 20 A (50 Hz, –1 dB): 1 MHz – 200 MHz
Maximum Load: 5 W (for f > 900 kHz)
Connector: BNC female
Dimensions: 188 × 53 × 28 mm
Maximum Wire Diameter: 23 mm
Material: Aluminium
Weight: 260 g
