Frequency Range: 9 kHz – 1 GHz
Max. cont. current: 16 A
Max. current, limited time 3 min: 25 A
Max Voltage (DC to 400 Hz): 250 V AC
Impedance (50 Hz): 1.4 Ω
AMN Impedance A, or B: (50 ± 10) Ω
Insertion loss (EUT – AE): Typ. 25…60 dB
Voltage Division Factor at the measuring port: (0 … –3) dB
EuT Connectors: N-female
Adapters available for:
Wing terminals M7×0.75 not unscrewable
BS1363 (UK Type G)
CEE 7/3 (Schuko)
Dimensions (W × H × D): 448 × 191 × 470 mm
Weight: 11.5 kg
