Frequency range (nominal): 9 kHz – 30 MHz
Frequency range (usable): 9 kHz – 120 MHz
Voltage gain (50 Ω load): > 10 dB
Amplitude flatness: Max. ±0.5 dB
1 dB compression point at input: 92 dBµV
Input impedance: Rin > 100 kΩ, Cin < 10 pF
Output impedance: 50 Ω
VSWR output: < 1.2 : 1
Noise at input (AV-detector, BW = 9 kHz, 150 kHz – 120 MHz): < -10 dBµV
Ambient temperature: -10° to +60°C
Power supply: +9.6 V NiMH
Current consumption: < 35 mA
Material of the housing: Aluminium
Dimensions: 105 × 125 × 50 mm
Weight: 680 g
Recommended charger: ACS 110
