Nominal Frequency Range: 300 MHz. ... 3 GHz
Usable Frequency Range: 250 MHz ... 5.5 GHz
Isotropic Gain: typ. 4 ... 7 dBi
Antenna Factor: 15 ... 35 ( 42) dB/m
Nominal Impedance: 50 Ω
Standing Wave Ratio (SWR) typical: 1.5 - 3
Front to Back Ratio: > 15 - 25 dB
Cross Polarisation Rejection: typ. 15 dB
3 dB Beamwidth typ. (E-Plane): 50° - 80°
3 dB Beamwidth typ. (H-Plane): 90° - 170°
Max. Input Power: 100 W (intermitt.), 50 W (cont.)
Connector: N-Connectors female
Mount: 22 mm Tube, Indexing Ring
Width × Length × Thickness: 540 x 695 x 540 mm
Weight: 1.2 kg
