Sensata Technologies - Crydom CWD4850P Indicator 0.15-50A 4-32VDC
Manufacturer: Sensata Technologies - Crydom Model: CWD4850P - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Width: 44.5 mm
Height: 30.9 mm
Length: 58.8 mm
IP Rating: IP20
Output Type: SCR
Unit Weight: 86.500 g
Contact Form: SPST (1 Form A)
REACH - SVHC: Details
Input Current: 10 mA to 15 mA
Mounting Style: Panel Mount
Termination Style: Screw
Relay Contact Form: 1 Form A (SPST-NO)
Load Current Rating: 50 A
Load Voltage Rating: 48 VAC to 660 VAC
Control Voltage Range: 4 VDC to 32 VDC
Pd - Power Dissipation: 500 mW
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 40 C
