Input
type of the power supply network: 1-phase and 2-phase AC
supply voltage at AC: Set by means of selector switch on the device; starting from Vin > 90/180 V
supply voltage 1 at AC: 120 ... 230 V
supply voltage 2 at AC: 230 ... 500 V
input voltage 1 at AC: 85 ... 264 V
input voltage 2 at AC: 176 ... 550 V
wide range input: Yes
overvoltage overload capability: 1300 Vpeak, 1.3 ms
buffering time for rated value of the output current in the event of power failure minimum: 25 ms
operating condition of the mains buffering: at Vin = 120/230 V, typ. 150 ms at Vin = 400 V
line frequency: 50/60 Hz
line frequency: 47 ... 63 Hz
input current
● at rated input voltage 120 V: 2.2 A
● at rated input voltage 230 V: 1.2 A
● at rated input voltage 500 V: 0.61 A
Output
voltage curve at output: Controlled, isolated DC voltage
output voltage at DC rated value: 24 V
output voltage
● at output 1 at DC rated value: 24 V
output voltage adjustable: Yes; via potentiometer
adjustable output voltage: 24 ... 28.8 V
relative overall tolerance of the voltage: 3 %
relative control precision of the output voltage
● on slow fluctuation of input voltage: 0.1 %
● on slow fluctuation of ohm loading: 0.1 %
residual ripple
● maximum: 50 mV
voltage peak
● maximum: 200 mV
