SIGLENT SHS820 Handheld Digital Oscilloscope (200MHz; 2CH; 500MSa/s)

Bandwidth: 200MHz

Channels: 2CH

Memory depth: 32kpts

Rise time: ≤​1.7ns

Real time sample rate: 500MSa/s

Equivalent sample rate: 50GSa/s

Time base range: 2.5ns/DIV~50s/DIV

Vertical sensitivity: 2mv/div~100v/div

Vertical resolution: 8 bit

Modulation type: Edge, Pulse, Video, Slope, Alternative

Data recorder: 7 Mpts

Trend plot: 800 Kpts

Triggering frequency counter: 6 digits

Interface: USB Device, USB Host

Multimeter specification

Maximum resolution: 6000

DC Voltage: 60mV-1000V; ±1%±15digit

AC Voltage: 60mV-750V; ±1.5%±15 digit

DC Current: 60mA-10A; ±5%±5 digit

AC Current: 60mA-10A; ±5%±5 digit

Capacitance: 40nF; ±4%±10digit

                      400nF-400μF; ±5%±5digit

Resistance: 600Ω-6MΩ; ±1%±5digit

                    60MΩ; ±4%±5digit

Continuity: <50Ω

Diode: 0-2V

Trend Plot: 1.2Mpts

Other specification

Display: 5.7 inch color TFT-LCD, 320*234

Power supply: Charging/Battery

Net weight: 1.5kg

Dimension: 163.2*259.5*53.3mm

Standard accessories

A 9V, 4A, power adapter

Two 1X/10X oscilloscope probes

Two test leads for multimeter

Probe calibration accessory

A USB data transmitting cable

Quick start

Certificate of calibration

Optional probe

100MHz high-voltage safety probe CAT II 1000V,CAT III 600V

200MHz high-voltage safety probe CAT II 1000V,CAT III 600V
