Siretta OSCAR20A/x/SMAF/S/S/15 Outdoor Antennas 5G/4G/LORA/SIGFOX/BLUETOOTH/ZIGBEE DIRECTIONAL YAGI ANTENNA SMA FEMALE NO CABLE

Gain: 7 dB to 10 dB

VSWR: 1.3:1

Width: 147 mm

Height: 35 mm

Length: 170 mm

Frequency: 600 MHz to 960 MHz, 1.71 GHz to 2.17 GHz, 2.2 GHz to 2.4 GHz, 2.5 GHz to 2.7 GHz, 3.3 GHz to 3.5 GHz

Impedance: 50 Ohms

Cable Type: RG58

Application: 2G/3G/4G/5G

Polarization: Vertical

Power Rating: 50 W

REACH - SVHC: Details

Mounting Style: Bracket Mount

Frequency Range: 600 MHz to 3.5 GHz

Number of Bands: 5 Band

Mechanical Style: Yagi

Maximum Frequency: 3.5 GHz

Minimum Frequency: 600 MHz

Termination Style: SMA Female

Antenna Connector Type: SMA Female

Maximum Operating Temperature: + 70 C

Minimum Operating Temperature: - 30 C

Protocol - Cellular, NBIoT, LTE: Cellular (NBIoT, LTE)
