Width: 63.5 mm (2.5 in)
Height: 31.75 mm (1.25 in)
Length: 107.95 mm (4.25 in)
Industry: Industrial
Approvals: EN60950-1, UL60950-1
Compliance: EN60950-1, UL60950-1
Unit Weight: 141.748 g
Output Power: 50 W
Input Voltage: 90 VAC to 264 VAC
Cooling Method: Convection
Mounting Style: Chassis
Load Regulation: Regulated
Mechanical Style: Open / Enclosed Frame
Number of Outputs: 3 Output
Input Voltage - Max: 264 VAC
Input Voltage - Min: 90 VAC
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 4 A
Output Current-Channel 3: 200 mA
Output Voltage-Channel 1: 5.05 VDC
Output Voltage-Channel 2: 15 VDC
Output Voltage-Channel 3: - 15 VDC
Operating Temperature Range: 0 C to + 50 C
Maximum Operating Temperature: + 50 C
Minimum Operating Temperature: 0 C
