Width: 50.8 mm (2 in)
Height: 25.4 mm (1 in)
Length: 76.2 mm (3 in)
Industry: Medical
Approvals: EN60601-1, UL60601-1
Compliance: EN60601-1, UL60601-1
Efficiency: 88 %
Unit Weight: 232 g
Output Power: 45 W
Input Voltage: 80 VAC to 270 VAC
Cooling Method: Convection
Mounting Style: Chassis
Mechanical Style: Open / Enclosed Frame
Isolation Voltage: 4.5 kVAC
Number of Outputs: 1 Output
Input Voltage - Max: 270 VAC
Input Voltage - Min: 80 VAC
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 3 A
Output Voltage-Channel 1: 15 VDC
Operating Temperature Range: - 20 C to + 70 C
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 20 C
