Width: 76.2 mm (3 in)
Height: 38.1 mm (1.5 in)
Length: 127 mm (5 in)
Industry: Medical, Industrial
Approvals: EN/IEC/UL62368-1, EN/IEC/UL60601-1-1
Efficiency: 90 %
Unit Weight: 490 g
Output Power: 420 W
Input Voltage: 85 VAC to 264 VAC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Number of Outputs: 1 Output
Power - Convection: 300 W
Power - Forced Air: 420 W
Open Frame/Enclosed: Open Frame
Output Current-Channel 1: 17.5 A
Output Voltage-Channel 1: 24 VDC
Maximum Operating Temperature: + 80 C
Minimum Operating Temperature: - 20 C
