Accuracy: EN837-1 Class 1.0 (±1.0% FSD)
Connection: ½” BSP Parallel, Bottom Entry
Dial: 160mm 304 St/St bayonet type bezel
Pressure Range(s): -30"Hg (-1 to 0) vacuum pressure range
Material: 316 St/St wetted parts
Ingress Protection: IP65
Operating Temp: -20 to +60°C
Window: Laminated Safety Glass
With e-Gauge-lite
Output Signal: 4-20mA (2-wire)
Nominal rating: 12-24 VDC
Accuracy: <0.25% of full-scale value
Linearity: <1.0%
Humidity Range: 0-99% RH NC
Measurement Frequency: >10Hz
IP Rating: IP67
Lead Length: 1.5m
Span: 270°
