Shutdown: No Shutdown
Topology: Quad
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Unit Weight: 250 mg
Qualification: AEC-Q100
Amplifier Type: Low Power
Mounting Style: SMD/SMT
SR - Slew Rate: 450 mV/us
THD plus Noise: 0.01 %
Number of Channels: 4 Channel
Supply Voltage - Max: 6 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 63 nA
Operating Supply Current: 145 uA
Ios - Input Offset Current: 1 nA
Output Current per Channel: 48 mA
Vos - Input Offset Voltage: 3 mV
GBP - Gain Bandwidth Product: 1 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 40 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 95 dB
PSRR - Power Supply Rejection Ratio: 90 dB
