Accuracy: 0.1 %
Gain V/V: 100 V/V
Shutdown: Shutdown
Gain Error: 0.3 %
Unit Weight: 28 mg
3 dB Bandwidth: 415 kHz, 490 kHz
Amplifier Type: Precision Bidirectional Amplifier
Mounting Style: SMD/SMT
SR - Slew Rate: 2.8 V/us, 5.2 V/us
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 350 uA
Operating Supply Current: 2.3 mA, 2.45 mA
Vcm - Common Mode Voltage: - 20 V to 70 V
Vos - Input Offset Voltage: 1.1 mV
GBP - Gain Bandwidth Product: 415 kHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
en - Input Voltage Noise Density: 100 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 120 dB
PSRR - Power Supply Rejection Ratio: 100 dB
