Dimension：LxWxH(mm)4350*1480*1750
Weigh:Approx.1800kg
Power Supply:3PH 380V 50HZ
Startup Power:32KW
Operation Powr Consumption:Approx.8KW
Control System:PC+PLC
Spraying movement:Step motor
Spray Pressure:0.2Mpa-0.4Mpa
Flux Flow Arrange:Option
Auto Fill Flux:Standard
Exhaust:Top exhaust+Side exhaust
Exhaust Ducting Diameter(mm):Φ250
Exhaust Capacity:30m³/min
Preheating Mode:Hot air Convection / IR
Control Mode:PID
Preheating Zone Number:3
Preheating Length(mm):1800
Preheating Temperature:Room temperature~200℃
Warm-upTime(min):Approx.12min(setting：150℃)
Blower Motor:250W 3PH 220VAC
PCB Width(mm):50-350
Convoyor Direction:L-R (Option：R-L)
Conveyor Speed(mm/min):500~1800
Conveyor Height(mm):750±20
Available Component Heigh (mm):Top 120 (Option： 240); Bottom 15
Conveyor Speed Control Mode:Frequency converter closed-loop stepless speed regulation
Fingers:Spring tablet finger /D-40 duckbill finger/double hook finger/heavy double hook finger, choose one.
Conveyor Angle:4-7°
Type of solder Pot:Motor drive
Solder Pot Material:Casting Iron
Wave Height Adjustment:Inverter Approx：Digital Control by PC
Cooling Method:Forced air cooling, Option: water cooler
Heater Power:13.5KW
Solder Pot Temperature:300℃
Solder Pot Capacity:Approx.480KG
Wave Drive Power:180W*2 3PH 220VAC
Solder Pot Warm-up Time:Approx.150min (setting：250℃)
Temperature Control Mode:PID
Finger Cleaning System:Brush
