Dimensions (mm): Φ40*95
Measuring range (m): 2.5m
Measuring accuracy: ±2mm, ±0.05%FS
Beam Angle: 6°Radar
Frequency: 60GHz
Radar Antenna: Planar microstrip pulse radar
Digital Interface: RS485 (Default) / RS232 (Optional) / SDI12 (Optional) / MODBUS Protocol
Analog Output: 4-20mA (Optional)
Sleep Time: 0-24h, configurable
Bluetooth Debugging: Bluetooth 4.2 or above, Transmit power +8dBm, Receiver sensitivity -95dBm at 0.1%BER
Protection Rating: IP68
Lightning Protection Level : 6KV
Operating Temperature: -35°C ~ 70°C
Storage Temperature: -40°C ~ 70°C
Operating Voltage: 7-32VDC (Default), 5.5-32VDC (Optional)
Operating Current (@DC12V): Operating mode ≤ 10mA, Sleep mode ≤ 0.5mA
