Gain: - 1 .9 dBi, 0.5 dBi, - 0.8 dBi
VSWR: 2.0:1, 2.0:1, 2.0:1
Style: Stacked
Width: 25 mm
Height: 4 mm
Length: 25 mm
Impedance: 50 Ohms
Cable Type: RF1.13
Application: Autonomous Vehicles, RTK Systems, Navigation, Robotics, Transportation, Telematics
Cable Length: 60 mm
Polarization: RHCP
REACH - SVHC: Details
Mounting Style: PCB Mount
Electrical Type: Active Embedded
Number of Bands: 3 Band
Center Frequency: 1.561 GHz, 1.57542 GHz, 1.602 GHz
Mechanical Style: Patch
Ground Plane Size: 70 mm x 70 mm
Maximum Frequency: 1.61 GHz
Minimum Frequency: 1.559 GHz
Termination Style: Pin
Antenna Connector Type: IPEX MHF1
Protocol - GPS, GLONASS: BEIDOU, Galileo, GLONASS, GNSS, GPS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
