Gain: 4.5 dBi, 2.33 dBi, 4.6 dBi, 4.7 dBi, 4.4 dBi, 4 dBi
VSWR: 5.2, 2.0, 1.9, 2.0, 1.8, 1.8
Style: I-Bar Flex
Width: 21 mm
Height: 0.2 mm
Length: 96 mm
Frequency: 698 MHz to 3 GHz
Impedance: 50 Ohms
Cable Type: 150 mm RF1.37
Application: Cellular Application, ISM Application, Satellite Application
Cable Length: 150 mm
Polarization: Linear
Power Rating: 5 W
Mounting Style: Adhesive Mount
Frequency Range: 698 MHz to 3 GHz
Number of Bands: 6 Band
Center Frequency: 700 MHz, 850 MHz, 900 MHz, 1575 MHz, 1700 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2400 MHz, 2600 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 3 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Protocol - Sub GHz: ISM
Antenna Connector Type: I-PEX MHF 4L
Protocol - GPS, GLONASS: Galileo, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiMAX
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, GPRS, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
