Taoglas WA.500w.301151 Passive Antenna Stingray WA.500w Glassmount 2.4/5.8GHz, 3M RG-174

Gain: 3.7 dBi, 3.65 dBi

VSWR: 1.92

Style: Dome

Length: 11.87 mm

Diameter: 5.1 mm

IP Rating: IP65

Impedance: 50 Ohms

Cable Type: RG174

Technology: WiFi

Application: Wireless Application

Unit Weight: 199.584 g

Cable Length: 3 m

Polarization: Linear

Mounting Style: Adhesive Mount

Number of Bands: 2 Band

Center Frequency: 2.45 GHz, 5.5 GHz

Mechanical Style: Module

Maximum Frequency: 5.85 GHz

Minimum Frequency: 2.4 GHz

Termination Style: Connector

Protocol - Sub GHz: IoT, ISM

Antenna Connector Type: RP-SMA Male

Protocol - WiFi - 802.11: 802.11, WLAN, WiFi, WiMAX

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C

Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE

Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
