TDK-Lambda PXB15-24WD15/N Isolated 15W 15V 0.5A
Manufacturer: TDK-Lambda Model: PXB15-24WD15/N - Contact
Call for the best price
Hanoi city: (024) 35.381.269
Danang city: (023) 63.747.711
Bac Ninh city: (0222)730.39.68
HCM city: (028) 38.119.636
Width: 25.4 mm (1 in)
Height: 9.91 mm (0.39 in)
Length: 25.4 mm (1 in)
Industry: Industrial
Dimensions: 1 in x 1 in x 0.39 in
Unit Weight: 15 g
Output Power: 15 W
Input Voltage: 9 V to 36 V
Mounting Style: Through Hole
Isolation Voltage: 1.6 kV
Number of Outputs: 2 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 500 mA
Output Current-Channel 2: 500 mA
Output Voltage-Channel 1: 15 V
Output Voltage-Channel 2: - 15 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
