Frequency range: 100 kHz – 150 MHz
DC Resistance: < 9 mΩ Source+ to DUT+; < 2 mΩ Source- to DUT-
Maximum current: 50A continuous, 70 A for 3 minutes
Nominal operating voltage range: 0 – 60V DC;
Component rating: 250V
High current plug/screw terminals – male: Phoenix Contact 1998933, female: Phoenix Contact 1967375
1µF capacitor can be disconnected internally by removing a jumper
Dimensions: 120 mm x 100 mm x 225 mm (270 mm including ground brackets); weight: 1.6 kg
