Telink TLSR9218AER Bluetooth, Zigbee Multi-protocol Connectivity SoC, 1MB Flash, temp -40? to 85?, 48 Pin Bluetooth LE 5.2, Bluetooth Mesh, AoA/AoD, 6LoWPAN/Thread, 802.15.4, Zigbee, HomeKit, Find My, Matter, 2.4G Proprietary, RTOS PSA Level 1 Certified

Core: RISC

Width: 6.1 mm

Height: 0.8 mm

Length: 6.1 mm

Technology: Si

Sensitivity: - 92.5 dBm

Output Power: 10 dBm

Data RAM Size: 64 kB

Data RAM Type: SRAM

ADC Resolution: 14 bit

Data Bus Width: 32 bit

Interface Type: I2C, I2S, SPI, UART, USB

Mounting Style: SMD/SMT

Number of I/Os: 32 I/O

Number of Timers: 2 x 32 bit

Maximum Data Rate: 2 Mbps

Moisture Sensitive: Yes

Operating Frequency: 2.4 GHz

Program Memory Size: 1 MB

Supply Voltage - Max: 4.3 V

Supply Voltage - Min: 1.8 V

Number of ADC Channels: 9 Channel

Maximum Clock Frequency: 32 MHz

Supply Current Receiving: 6.1 mA

Supply Current Transmitting: 6.6 mA

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
