Width: 9.14 mm
Height: 4.45 mm
Length: 9.14 mm
Shutdown: No Shutdown
Input Type: Rail-to-Rail
Technology: Bipolar
Supply Type: Dual
Unit Weight: 1.570 g
Mounting Style: Through Hole
SR - Slew Rate: 500 mV/us
Voltage Gain dB: 104.08 dB
Number of Channels: 1 Channel
Dual Supply Voltage: +/- 9 V, +/- 12 V, +/- 15 V, +/- 18 V
Supply Voltage - Max: 44 V
Supply Voltage - Min: 10 V
Pd - Power Dissipation: 1.2 W
Ib - Input Bias Current: 30 nA
Operating Supply Current: 1.8 mA
Operating Supply Voltage: 10 V to 44 V
Output Current per Channel: 27 mA
Vos - Input Offset Voltage: 700 uV
Maximum Dual Supply Voltage: +/- 22 V
Minimum Dual Supply Voltage: +/- 5 V
GBP - Gain Bandwidth Product: 1 MHz
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.1 pA/sqrt Hz
en - Input Voltage Noise Density: 15 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 96 dB
