Source voltage: 380V/50Hz/Three phase. Customized according country request
Power: 4KW
Compressed air: 0.6MPa with 0.04 M3/min flow
Cutting materials: 50-300um thickness battery electrode made by 9-30um aluminum foil or copper foil with coating, rolling press.
Unreeling mode: Uniaxial passive unreel, automatic correction, constant tension control
Material roller size: Max Dia500*Width500mm
Max cutting width: ≤520mm
Reel and Unreel roller: Slip gas rose axis with diameter 76.2mm(3 inches)
Reel and Unreel weight: 150～300kg
Cutter knife diameter: φ130mm
Cutting burr: ≤10μm without Without a ripple
Machine roller width: 650mm
Machine speed: 50m/min, continuous and adjustable
Cutting accuracy: ±0.1mm
Dimension (L*W*H): 1800*1800*1600mm
Weight: 2000kg
