Power: 3PH 380V，50HZ,
Suitable system: LiFePO, lithium cobalt oxide,Lithium manganese oxide system and coating process of battery anode and cathode
Operating material thickness
Al foil: 10~30um
Cu foil: 7~30um
The design of the roll surface width: 300mm
Guaranteed coating width: 50~280mm
Mechanical running speed of equipment: 7m/min
Coating speed: 1-7m/min（Depending on the drying condition）
Suitable for slurry viscosity: 2000~16000 Cps
Single coating thickness range:50-150μm
Minimum interval length: 5mm
Multi section minimum coating length: 20mm
Solvent properties
Oiliness solvent NMP(s.g=1.033,b.p=204℃)
Water solvent H2O/NMP(s.g=1.000,b.p=100℃)
Suitable solid content
Anode S.C. 60% ± 20%
Cathode S.C. 60% ± 20% (PVDF system)
S.C. 50% ± 5% (SBR system)
Specific gravity
Anode: 1.5—2.59/cm2
Cathode: 1~1.89/cm2
Coating method:Double sides 3 sections, unequal intermittent transfer coating / second sides automatic tracking / continuous transfer coating
Base material running direction: Forward coating ,The base material empty foil movement Positive, reverse.
Control pressure: 0 ~ 50N
Rectify deviation: EPC control，stroke 80mm
Oven length: 12m
Material quality: SUS304 stainless steel,Inner tank 1.0mm,outside tank 1.2mm
Transfer interval coating machine,the coating thickness is easy to adjust,more accuracy,easy to operate.it can do both continuous coating and interval coating.
