Width: 9.9 mm (0.39 in)
Height: 12.5 mm (0.492 in)
Length: 19.6 mm (0.772 in)
Industry: Medical, Industrial
Compliance: IEC/EN/ES60601-1, IEC/EN/UL62368-1
Unit Weight: 4.800 g
Output Power: 1 W
Mounting Style: Through Hole
Isolation Voltage: 5 kV
Number of Outputs: 2 Output
Input Voltage - Max: 28.8 V
Input Voltage - Min: 19.2 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 42 mA
Output Current-Channel 2: 42 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
