Air flow rate max. [m³/h]: 9,000
Heating capacity [kW / kcal]: 120/ 103,181
Air pressure [Pa]: 600
Air discharge temperature max. [°C]: 65
Temperature increase (ΔT) max. [°C]: 60
Fan [kW]: 5.4
Controls: Switch with eight stages for air volume and air temperature
Stage 0
Air flow rate [m³/h]: 9,000
Temperature increase (ΔT) [°C]: –
Stage 1
Air flow rate [m³/h]: 9,000
Temperature increase (ΔT) [°C]: 15
Stage 2
Air flow rate [m³/h]: 9,000
Temperature increase (ΔT) [°C]: 25
Stage 3
Air flow rate [m³/h]: 9,000
Temperature increase (ΔT) [°C]: 40
Stage 4
Air flow rate [m³/h]: 6,000
Temperature increase (ΔT) [°C]: –
Stage 5
Air flow rate [m³/h]: 6,000
Temperature increase (ΔT) [°C]: 15
Stage 6
Air flow rate [m³/h]: 6,000
Temperature increase (ΔT) [°C]: 40
Stage 7
Air flow rate [m³/h]: 6,000
Temperature increase (ΔT) [°C]: 60
Input voltage [V / Hz]: 400 / 50-60
Current consumption max. [A / kW]: 128 / 125.5
Fuse protection [A] / plug: 200 / direct connection
Sound level (distance 3 m) [dB(A)]: 76
Hose connector ø [mm]: 450
Suitable for hose lengths up to [m]: 100
Mobility: wheelable / fork lifter / crane
Length [mm]: 1,920
Width [mm]: 950
Height [mm]: 1,450
Weight [kg]: 460
Minimum cable diameter [mm]: 95
Overheating protection: yes
