Aerosol Type: Paraffin Oil (EN setting for oil)
Generator Model: 1081414R-EN
Count Median Diameter (CMD): 0.16 µm
Mass Mean Diameter (MMD): 0.4 µm
Geometric Std. Deviation (GSD): ~ 2
Concentration: 20 ± 5 mg/m3
Ambient Pressure: 75 to 110 kPa (absolute)
Ambient Temperature: 10°C to 35°C
Operating Humidity: 0% to 95%, non-condensing
Technique: Light-scattering, laser photometer
Dynamic Range: 1.0 µg/m3 to >200 mg/m3
Volumetric Flow: TSI Mass Flow Meter 4045 (pressure/temp compensated)
Flow Rate through Media: Adjustable from 10 to 110 L/min
Accuracy: ±2% of reading
Technique: Electronic pressure transducer
Range: 0 to 250 mm H2O (0 to 2500 Pa)
Accuracy: ±1% of full scale
Operating Range: Measures particle penetrations up to 99.9999%
Note: Sensitivity for salt aerosol is less than oil at 200 mg/m3
Power: 90 VAC to 250 VAC, 50 Hz to 60 Hz, 5.5 A continuous
Compressed Air: 80 psig, 7 scfm (550 kPa, 198 std. L/min)
Dimensions (L x W x H): 70 cm x 70 cm x 147 cm (28 in. x 28 in. x 58 in.)
Weight: 150 kg (330 lb)
Display/Output: Color touch screen, RS-232
Built-in Internal Pump: Included (Vacuum pump)
Filter Holder: Included for flat sheet media and gravimetric filter holder
