Size Range: 0.100 – 10.0 µm
Particle Channels: 9110-01: 0.10; 0.15; 0.2; 0.25; 0.3; 0.5; 1.0; 5.0 µm
Size Resolution: <15% @ 0.2 µm (ISO 21501-4)
Counting Efficiency: 50% @ 0.100 µm; 100% >0.15 µm
Concentration Limit: 100,000 particles/ft³ @ 10% coincidence loss
Light Source: HeNe laser
Flow Rate: 1 CFM (28.3 L/min) ±5%
Sampling Modes: Manual / automatic; cumulative / differential
Sampling Time: 1 second – 99 hours
Cycles: 1 – 9999 or continuous
Exhaust: Internal HEPA filter
Communication: Ethernet (Modbus TCP), USB
Display: 5.7-inch touchscreen
Software: TrakPro™ Lite Secure, FMS
Data Storage: 10,000 records; 250 zones; 999 locations
Alarms: Audible >85 dB; dry contact; programmable limits
Security: 2-level password; configurable IP
Power: 110–240 VAC
Battery: Li-Ion (up to 4), ~4 hours operation
Dimensions: 23.6 x 20.6 x 52.2 cm
Weight: 11.14 kg (without battery) / 12.7 kg (with battery)
Operating Conditions: 10–35°C; 20–95% RH
Storage Conditions: 0–50°C; ≤98% RH
