Intensity range:
850 nm: 40 – 200 [μW/cm²]
940 nm: 30 – 150 [μW/cm²]
Intensity unevenness [±%]: 2.5
Light source: LED
Lighting method: DC
Wavelength [nm]: 850, 940
Function:
Change input intensities
Fine tune IR intensity
Switch IR wavelengths
IR intensity feedback function
Display / Operation:
The main operation part
External communication control (serial)
Communication I/F:
Connector: USB 2.0 Type-B
UART by visual COM port with USB port
Power supply voltage: AC100–240V, 50/60Hz
Power consumption [VA]: 100
Operating environment: Temperature 15–30℃; Humidity less than 80% without dew condensation
Dimensions (WxHxD) [mm]: 186×195×67
Weight [kg]: 0.54
Extension functions:
Change the size of light surface and IR intensity
Change wavelengths (850 nm, 940 nm, 1050 nm, 1300 nm, 1550 nm)
Upgrade maximum IR intensity
