Life: 100000 Cycle
Taper: Linear
Width: 10.7 mm
Height: 11.35 mm
Length: 10 mm
Features: Top Adjust
IP Rating: IP50
Tolerance: 20 %
Resistance: 5 kOhms
Shaft Type: Flatted / D
Orientation: Vertical
Switch Type: No Switch
Thread Size: M7 x 0.75
Unit Weight: 8.131 g
With Switch: No Switch
Bushing Size: 5 mm
Element Type: Conductive Plastic
Power Rating: 25 mW (1/40 W)
Shaft Length: 20 mm
Bushing Thread: M7 x 0.75
Mounting Style: Panel Mount
Shaft Diameter: 6 mm
Voltage Rating: 50 VAC
Number of Gangs: 1 Gang
Number of Turns: 1 Turn
Bushing Material: Metal
Number of Detents: Without Detent
Termination Style: PC Pin
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 10 C
