-Resistance Specification:
Nominal resistance ( Ω ): 50
Initial deviation [1] (±μΩ/Ω ) @ (23±1)°C: 50
Annual Stability ( ±μΩ/Ω ): 18
Temperature coefficient (ppm/K): 2.5
Power factor [2] (±ppm/Rated power): 1
-Current Measurement:
Nominal input current (A): 20 m
Nominal Output current (V): 1
AC/DC difference[3] (±ppm): 50 Hz: 20; 1 kHz: 25; 100 kHz: 50
Maximum operating current (A): 40 m
Instantaneous current (A, <5 s): 250 m
-Phase Displacement ( ±μrad ):
53 Hz: 5; 400 Hz: 5; 1 kHz: 10; 10 kHz: 100; 50 kHz: 400; 100 kHz: 800
-General Specifications:
Power supply: ——
Temperature performance: Operating temperature: 13 °C ~ 33°C; Calibration temperature: 18°C~28°C; Storage temperature: 5°C to 45 °C
Note: When stored in a harsh temperature environment, the resistance value may change temporarily and be restored to the original resistance value within the following 30 days.
Humidity performance: Operating humidity: < 50% R•H; Storage humidity :(15%~80%) R•H, no condensation
Connection mode:
Input connection: 1 mA~20 A specifications using Type-N female plug; Type-LC female plug for 50 A and 100 A specification;
Output connection: All specifications use Type-N female plugs.
Size (mm) (W * D * H) (excluding terminals): 90 *25 *25
Weight (kg): 0.1
