Display: 2.4" TFT (302x240)
IR resolution(Pixels): 160x120
Super resolution(Pixels): (640x480)
Pixel size: 12μm
Frame rate: ≤25Hz
Thermal sensitivity(NETD): ≤50mK
Focus: focus free
Field of view(FOV): 40ºC x 30º(V)
Temperature measurement range: -20 ºC~550 ºC
Accuracy: ±2ºC or ±2% whichever is greater
Functions:
Color palettes: white hot, black hot, ironbow, lava, rainbow, rainbow HC
Image modes: thermal, visual image, fusion (T-mix), PIP
Temperature compensation: -
Hi/Lo temperature alarm: LCD animation, LED flashlight, Buzzer
Hi/Lo temperature tracking: yes
Digital camera resolution: 2MP
Laser pointer / LRF: yes/-
LED lighting: yes
Analysis software: PC
General Characteristics
Battery: 2600mAh rechargeable Li-ion battery
Operating time: ≥6h
USB: Type-C
Storage: 32GB internal
Image storage format: JPG
Protection: IP54 & 2m drop proof
Certificates: CE, FCC, RoHS
Languages: EN, FR, ES, IT, SV, CZ
Weight: 326g
Dimension: 197x72x60mm
