VICTOR VC9807A+ Digital Multimeter (1000VDC, 50VAC, 20ADC/AC, True RMS)

DC Voltage

200mV/2V/20V/200V ±(0.1%+5)

1000V ±(0.2%+5)

AC Voltage

200mV ±(1.0%+25)

2V/20V/200V ±(0.8%+25)

750V ±(1.2%+50)

DC Current

200uA/2000uA/20mA ±(0.5%+4)

200mA ±(0.8%+6)

20A ±(2.0%+15)

AC Current

20mA ±(1.5%+15)

200mA ±(1.5%+15)

20A ±(2.5%+35)

Resistance

200Ω ±(0.4%+10)

2kΩ/20kΩ/200kΩ ±(0.4%+5)

2MΩ ±(1.2%+25)

20MΩ/200MΩ ±(5.0%+45)

Conductance: (0.1~100)nS ±(1.0%+30)

Capacitance: 20nF/200nF/2uF/20uF/200uF/2mF ±(4.0%+50)

Frequency: 200Hz/2kHz/20kHz/200kHz/2MHz ±(0.1%+3)

Special Function

Diode √

Transistor test √

Continuity buzzer √

Low battery indication √

Data Hold √

Auto power off √

Backlight √

Function protection √

Shockproof protection √

True RMS √

Input impedance: 10МΩ

Sampling rate: 3 times/s

AC Frequency response: 40~1000Hz

Operation way: Manual range

Max. Display: 19999

LCD size: 70×50mm

Battery : 1.5V AAA LR03 Battery
