International Standard: ASTM D 5289; ISO 6502; KS M ISO 6502
Motor: Induction Motor
Die configuration: Biconical, closed die system, sealed
Oscillation frequency: 1.67Hz
Oscillation angle: 0.5°[Option]1°, 3°, 5°; Mechanically adjustable
Protection for operator Temp. shield screen moving: Before test chamber closing
Test chamber moving: By Pneumatic
Motor Platen operation: available by hardware & software
Temperature control: available by hardware & software
Temperature range: microprocessor controlled RT ~ 220°C
Temp. Sensor Type: PT 100 Ω
Torque range: 0~ 200 dNm
Calibration: Calibration jig
Data:
Torque[dNm, lbf.in]
Temperature [°C]
MH, ML Ts1, Ts2, Tc10(N), Tc50(N), Tc90(N)
Automatic test results pass/fail function
Trend graphs
Tolerance limits by time and torque
Data excel export function, Average, S-Dev
Pneumatics: min 4.5 bar/60 Psi
Electrical: 200~230V, 3A, single phase, 50Hz/60Hz
Emergency Button
Dimension: W615 X D685 X H1200 mm
Weight: 160 kgs
