Max. swing over the bed: 250mm
Max. length of work piece: 500mm
Max. swing over cross slide: 150mm
Spindle bore: 26mm
Spindle taper: MT4
Max. cross slide travel: 130mm
Max. longitudinal stroke over tool post: 60mm
Metric thread kinds: 9
Metric pitches: 0.25-2.5mm
Inch threads kinds: 15
Inch pitches: 12-96TPI
Longitudinal-feed range: 0.025-0.250mm/r
Cross-feedrange: 0.0125-0.125mm/r
Max. travel of tailstock taper: 60mm
Tailstock sleeve taper: MT3
Spindle speeds range: 12 steps: 80-2000r/min
Motor: 750W
Net weight (without base): 180/200kg
Packing size (without stands): (L×W×H) 1160x640x580mm
