Max. swing diameter over bed: 360mm
Max. length of work piece: 750mm
Max. swing diameter over middle carriage: 200 mm
Spindle bore: 40mm
Taper of hole in spindle: MT5
Max. cross stroke over tool carrier: 160mm
Max. longitudinal stroke over tool carrier: 100mm
Metric thread kinds: 22
Metric thread pitch: 0.20-7mm
Inch thread kinds: 45
Inch thread pitch: 21/2-48 1/n″
Longitudinal feed on spindle tool carrier: 0.10-1.40mm/r
Cross feed on spindle tool carrier: 0.045-0.60mm/r
Max stroke on taper hole: 80mm
Taper of Tailstock: MT3
Step of spindle speed: 12
Range of spindle speed: 60-1600r/mim
N.W.: 420kgs
G.W.: 470kgs
Overall size(L×W×H): 1580×785×1390mm
Packing size(L×W×H): 1600×800×1500mm
