External grinding diameters: φ8～200mm
Center height: 135mm
Max. worktable traverse: 600mm
Hydraulic travel speed: 0.1～4m/min
Max.workpiece weight: 50kg
Grinding length External: 500mm
Swivel range of worktable: -5°～+7°
Max.wheel peripheral speed: 35m/s
External wheel size: Max.φ400x50xφ203mm, Minφ280x50xφ203mm
Headstock and tailstock center: NO.4 morse
Total motor power: 5.43kW
Machine overall dimension（LxWxH): 2500x1800x1650mm
Machine weight: 3040kg
Roundness: 1.5μm（O.D）
Uniformity of dia.in longitudinal section: 5μm（O.D）
Surface roughness: Ra0.32μm（O.D）
