Swing over bed: 420mm
Distance between centers: 500mm
Max. longitudinal travel: 400mm
Max. cross travel: 200mm
Spindle taper: MT4
Spindle bore: φ28mm
Step of spindle speed: 7 steps
Range of spindle speed: 160-1360rpm
Metric thread range: 0.2-6mm
Inch thread range: 4-120T.P.I
Longitudinal range of automatic feeding: 0.05-0.35mm/ 0.002-0.014″
Cross range of automatic feeding: 0.05-0.35mm/0.002-0.014″
Max. drilling capacity: φ22mm
Worktable size (L×W): 475×160mm
Max. end mill: φ28mm
Max. face mill: φ80mm
Distance between spindle center and column: 285mm
Distance between spindle and worktable: 306mm
Headstock travel of up and down: 110mm
Spindle taper: MT3
Step of spindle speed: 16steps
Range of spindle speed: 120-3000rpm
Swivel degree of headstock: ±360°
Motor power: 0.75kw
Packing size: 1130×580×1100mm
N.W/G.W: 245/280kgs
