Max.swing over bed: Ф670mm
Max.swing over carriage: Ф380mm
Max. cutting length: 1500mm
Rail width: 550mm
Spindle bore: Ф225mm
Taper of spindle bore: MT6
Chuck size: 500mm
Range of spindle speed (L): 25-120rpm(H):100-500rpm
X-axis travel: 350mm
Z-axis travel: 1250mm
X/Z rapid speed: 4m/min
Electronic turret: 4 -station
Max.section of tool: 32x32mm
Stroke of tailstock sleeve: 250mm
Diameter/Hole of tailstock sleeve: Ф100mm/MT5
Main motor power: 11kW
Overall dimensions (L x W x H): 3657×1555×1360mm
Packing size (L x W x H): 3857×1755×1560mm
Net weight: 4600kg
Gross weight: 5600kg
