Max.swing over bed: Ф800mm
Max.swing over carriage: Ф480mm
Max. cutting length: 1500mm
Rail width: 600/755
Spindle bore: Ф280mm
Chuck size: 630mm
Range of spindle speed (L):20-100rpm(H):100-300rpm
X-axis travel: 450/550mm
Z-axis travel: 1250mm
X/Z rapid speed: 400mm/min
Electronic turret: 4 -station
Max.section of tool: 280x280mm
Stroke of tailstock sleeve: 250mm
Diameter/Hole of tailstock sleeve: Ф100mm/MT6
Main motor power: 15kW
Overall dimensions (L x W x H): 4600×2060/2100x2100mm
Packing size (L x W x H): 4800×2260/2300x2300mm
Net weight: 7000/9000kg
Gross weight: 8000/10000kg
