Workbench size (length×width): 1350×1000mm
Maximum load-bearing capacity of worktable: 5000kg
Worktable T-slot size (quantity～width×spacing): 7～22×125mm
Transverse travel of worktable (X axis): 1600mm
Vertical travel of headstock (Y axis): 1200mm
Longitudinal travel of sliding seat (Z axis): 1200mm
Axial stroke of boring shaft (W axis): 550mm
Distance from spindle center line to worktable: 0～1200mm
Boring shaft diameter: φ130mm
Maximum tool weight: 25Kg
Rated torque of boring shaft: 1500Nm
Spindle motor power: 15/18.5 KW
Inner hole taper of boring shaft: MAS 403(45°) BT50
Speed of Boring Shaft: 12～1500rpm
Rapid traverse speed: X/Y/Z axis: 10 m/min
Rapid traverse speed: W axis: 5m/min
Feed rate: X/Y/Z/W axis: 5～2000 mm/min
Positioning accuracy X/Y/Z axis: 0.030 mm
Positioning accuracy W axis: 0.025 mm
Repeat positioning accuracy X/Y/Z axis: 0.020 mm
Repeat positioning accuracy W axis: 0.016mm
Ball screw size (X/Y/Z): Ф63×10 mm
Ball screw size (W): Ф50×10 mm
Machine weight: About 18000kg
CNC controller: FANUC OI MF plus
Total electrical capacity: 65KVA
Machine size (L×W×H): 7100×6600×3600 mm
