Table size: 1320*1010mm
Max. allowable torque on spindle: 1100N.m
Max. allowable torque on facing head tool holder: 1100N.m
Max. allowable axial feed force on spindle: 13000N
Spindle speed range: 12-1100r/min
Facing head speed range: 4-130r/min
Rapid feed speed of spindle: 3600mm/min
Rapid feed speed of facing head radial tool holder: 1180mm/min
Spindle diameter: 110mm
Distance range from spindle nose to table surface: 5~905mm
Vertical travel of headstock: 900mm
Spindle axial travel: 550 mm
Radial travel of facing head tool holder: 160 mm
Longitudinal travel of table: 1350 mm
Cross travel of table: 1250 mm
Max. boring diameter of spindle: φ240 mm
Max. diameter of facing head tool holder: φ630 mm
Max. drilling diameter: φ50 mm
Spindle taper: BT50
Main motor power: 11/15kW
Rapid feed speed of X,Y,Z: 5000mm/min
Positioning accuracy of coordinate: X, Z: 0.04 mm, Y: 0.032mm
Positioning accuracy: 0.02/500mm
Repeat positioning accuracy: 0.014/500
Overall dimension(L*W*H): 5375×2995×3035 mm
Net. weight: 12300kg
