Boring spindle diameter: 130mm
The spindle taper hole: ISO7:24No50
Maximum spindle torque: 3136N.m
Maximum torque of flat disk: 4900N.m
Maximum axial resistance of spindle: 31360N
Maximum travel of spindle: 900mm
Spindle speed range: 4-800r/min
Slider travel of flat rotary disk: 250mm
Working area of table: 1800×1600mm
The table can bear the maximum weight: 10000kg
Distance from the center line of the spindle to the working table: 0~1800mm
Longitudinal bench stroke: 2000mm
Transverse bench stroke: 2000mm
Rapid feed speed of spindle, headstock and worktable in vertical and horizontal direction: 2500mm/min
Feed range of spindle, spindle box, table per Spindle: 0.05-8/0.01-2
Main motor power: 15kw
Machine tool dimension(LxWxH): 7030×4665×3800
Machine weight: 29300kg
