Height of center: 400mm
Swing over bed: 800mm
Swing over gap: 1046mm
Swing over cros slide: 580mm
Distance between center: 1500/2000/3000mm
Width of bed: 400mm
Travel of cross slide: 420mm
Travel of top slide: 235mm
Headstock and main spindle
Spindle nose, internal taper: 1:20
Spindle bore: 105mm
Range of spindle speeds: 25~1600rpm V: 16~70&50~215rp
Threads and Feeds
Metric threads range: 0.45~120mm
Imperial threads range: 7/16~80TPI
Longitudinal feeds: 0.044~1.48mm/U
Cross feeds: 0.022~0.74mm/U
Tall stock
Tailstock quil diameter: 90mm
Tailstock quil travel:230mm
Taper of tailstock quil: MT5
Motor
Main motor: 7.5KW or 11kW
Coolant pump: 90W
Rpaid movement motor: 550W
Weight: 3820kg
Packing size" 5287x1525x1925mm
