Worktable size (LxW): 700x210mm
Max. loading on worktable: 200kgs
T-slot size: 4x12mm
X/Y/Z axis travel: 360/260/440mm
Distance from spindle center to column: 270mm
Distance from spindle nose to worktable: 60-405mm
Spindle taper: BT30
Main motor power: 2.2/3.7kw
Max.spindle speed: 6000-8000rpm
Max.feed speed: 10m/min
Rapid feed speed: 10-12m/min
Main motor torque (servo): 14/23.7N.m
X/Y/Z axis ball screw: 5512
Max.length of tool: 300mm
Tool change time(T-T): 3s
Positioning accuracy (X/Y/Z): ±0.02mm
Re-positioning accuracy (X/Y/Z): ±0.01mm
Feeding motor power: 1.5kw
Feeding motor torque: 6N.m
Over size (LxWxH): 1470x1550x2080mm
Weight: 1200/1300kg
