Worktable size (LxW): 200x600mm
Max. loading on worktable: 50kgs
T-slot size: 12x45mm
X/Y/Z axis travel: 350/240/310mm
Distance from spindle center to column: 268mm
Distance from spindle nose to worktable: 38-348mm
Spindle taper: R8
Main motor power: 1kw
Feeding motor (step motor) X/Y/Z: 6Nm/6Nm/6Nm
Feeding speed: 0-3000mm/min
Min set unit: 0.001mm
Net weight: 580kg
Machine size: 148/130/185cm
