Worktable size: 400×125mm
T-slot size: 3×8×35
Loading capacity of worktable: 20kg
X axis travel: 260mm
Y axis travel: 110mm
Z axis travel: 180mm
Distance from spindle nose to worktable surface: 60-240mm
Distance from spindle center to column: 125mm
Spindle taper: MT2
Spindle power: 500w
Spindle speed: 100-7000r/min
X/Y/Z rapid feed speed: 2000mm/min
X/Y/Z axis torque: X/Y:1.35 Nm Z: 2.2Nm
Positioning accuracy: 0.015mm
Re-positioning accuracy: 0.01mm
Voltage: 230/120V
N.W/G.W: 280/340kg
Machine size (LxWxH): 1040×860×940mm
Packing size (LxWxH): 1170×960×1100mm
