X axis travel: 350mm
Y axis travel: 160mm
Z axis travel: 400mm
Spindle nose to table distance: 476.4mm
Spindle center to column distance: 161mm
Worktable size: 600X163mm
Main motor: 3KW
Spindle speed: 18000rpm
Coolant system: liquid cooling
Spindle taper: BT30
Capacity of ATC: 8T
Air compressor pressure: 12L
Lubricating pump capacity: 1L
Working light: 10W
Cooling pump: 40W
Controller system: after1500MDC-4
XY axis servo motor torque: 2.4N.M
Z axis servo motor torque: 4N.M
XYZ fast moving speed: 8
XY Linear guideway: 15mm（Taiwan HIWIN）
Z linear guideway: 20mm（Taiwan HIWIN）
X axis ball leadscrew: 1605（Taiwan TBI）
YZ axis ball leadscrew: 2005（Taiwan TBI）
